How does a car's transmission system work and what are the different types?

Question

msc545 · Accepted Answer

ChatGPT says:

"An automobile automatic transmission is a type of transmission that automatically changes gears while the vehicle is being driven. This type of transmission is designed to provide smooth and effortless gear changes, allowing the driver to focus solely on steering and accelerating. The transmission system is one of the most important components in a vehicle, as it directly affects the vehicle's performance and fuel efficiency.

The main components of an automatic transmission system are the torque converter, planetary gear sets, hydraulic pumps, and control valves. The torque converter is a fluid coupling device that transfers power from the engine to the transmission. The planetary gear sets are responsible for changing the gears by using different combinations of gears that are connected to the input and output shafts. The hydraulic pumps are used to apply pressure to the planetary gear sets, allowing them to engage or disengage. The control valves, which are controlled by the vehicle's computer, regulate the pressure that is applied to the planetary gear sets.

The basic operation of an automatic transmission system is based on the principle of hydraulic control. When the vehicle is accelerated, the engine creates torque that is transmitted to the transmission through the torque converter. The transmission's computer, which is connected to various sensors throughout the vehicle, determines the appropriate gear ratio based on the vehicle's speed and load. The computer then activates the control valves, which apply pressure to the appropriate planetary gear set. The gear set then engages and changes the gear ratio, allowing the vehicle to accelerate.

The transmission also includes several gearsets, each designed for a specific range of speeds. The lower gears are designed for low speed and high torque, while the higher gears are designed for high speed and low torque. When the vehicle reaches higher speeds, the computer will automatically shift to a higher gear to allow the engine to operate at a more efficient RPM. This process continues until the vehicle reaches its top speed or the driver decelerates.

In addition to the hydraulic control system, automatic transmissions also feature a number of safety features. For example, the transmission system may include a lock-up torque converter, which locks the torque converter in place when the vehicle reaches a certain speed. This feature helps to improve fuel efficiency and reduce wear on the transmission components.

In conclusion, an automobile's automatic transmission system is a complex and sophisticated component that plays a crucial role in the performance and efficiency of a vehicle. By using hydraulic control and planetary gear sets, the transmission system allows the vehicle to smoothly and efficiently change gears, allowing the driver to focus on driving. With its various safety features and efficient operation, the automatic transmission system has become a standard component in modern vehicles."

ChatGPT !

SpokenTruth · Accepted Answer

It transmits the power from the engine to the wheels that propel the vehicle in motion. Without it the power wouldn't be controllable or equalized. For instance if you started the car it would take off in whatever direction it was set to go in. It would also do it abruptly.

You have the standard transmission the automatic both with or without the overdrive feature added to it. The overdrive feature is a higher gear or the highest gear to reach. Also in the older cars there was about a 85 or 89% loss between the transmission and the engine. So they added what is known as the centrifungle clutch that produced a 1 to 1 ration around the same time as the overdrive became so popular.

PrettyPriya · Accepted Answer

Hmm, I think there could be a select few users here that could give a detailed explanation of the workings of a transmission. I don't drive that much. If we do use our car, my SO drives. It is very rare that I have to, so I would not be able to explain.

I can say this, I know there is automatic and manual transmissions. I have only ever driven the automatic type that does the work for you. Two pedals are enough for me without having a third and working more than I have to.

I tend to take ride share or public transportation because it is more practical in a large city. Traffic is just awful around here so not much use for a vehicle other than to get out of the city for a weekend.

I am sure there is great information on the interwebs about how all that functions. For me, it is press button, start car and pick correct pedal to move. Sorted.

Astarlessnightsky · Answer

The power from the engine isn't directly transfered to the wheels but instead goes through a variety of gears and depending on how big the wheels are you got different power levels on the wheels.

Eg lower power for starting the car and driving uphill.

Or high power which can only be effective when the car is already running but will than drive even faster.

Or an additional gear to turn the forward motion backwards.

RavVid · Answer

Essentially it is gears that mesh together. say the gear off the engine has 10 teeth and it drives a gear with 20 teeth than that gear will rotate half as fast. If the driven gear had 5 teeth it would rotate twice as fast as the engine.

Manuals and automatic differ a lot after that basic. clutches/torque converters are part of the transmission.

John_Doesnt · Answer

It begins with the AllSpark and ends with explosions.

MrOracle · Answer

Here ya go.

OlderAndWiser · Answer

The transmission is the most complicated mechanical component in your car. There are no simple explanations that adequately cover the workings of a transmisson. Take a course in auto mechanics, or at least look at some YT videos.

Redstang88 · Answer

The ones you’ll see in road vehicles are clutch style manuals, dual clutch / semi automatic, torque converter autos and CVTs (continuously variable). Far to complicated to explain here

Guy13 · Answer

I do not understand the details well enough to day in details.

italianduce · Answer

Son, leave these chores

LemiaOfThunder · Answer

Kenetic motion
